- Type: IP Camera
- Style: Bullet Camera
- High Definition: 2.0 Megapixels
- Connectivity: WIFI
- Lens (mm): 2.8mm
- Supported Operating Systems: Windows 10
- Supported Operating Systems: Windows 2008
- Supported Operating Systems: Windows 2000
- Supported Operating Systems: Windows Vista
- Supported Operating Systems: windows 8
- Supported Operating Systems: Windows 7
- Supported Operating Systems: Windows 98
- Supported Operating Systems: Mac OS
- Supported Operating Systems: windows xp
- Supported Operating Systems: Windows 2003
- Model Number: USA-IMX307-XK6D S
- Sensor: CMOS
- Technology: INFRARED
- Special Features: Waterproof / Weatherproof
- Sensor Brand: SONY
- Supported Mobile Systems: ios
- Supported Mobile Systems: Android
- Alarm Action: FTP Photo
- Alarm Action: Email Photo
- Alarm Action: Local Alarm
- Power Supply(V): DC 12V 2A
- Network Interface: RJ-45 10/100Mb Ethernet Slot
- Dimensions (L x W x D)(mm): 2
- IR Distance(m): 50
- Video Compression Format: H.264
- Minimum Illumination(Lux): 0
- Wall Bracket: Ceiling
- Color: White
- Installation: Ceiling
- Storage: None
- Power Supply: Normal
- TF Card: None
- Megapixels: 2MP
- Brand Name: OUWDRES
|
Model No. |
USA-SLH |
|
VIDEO |
|
|
Main PCB |
XM510+62 For 720P(H.264) XM510+H65 For 960P (H.264) HI3516E+2235 for 1080P(H.265) This H.265 must work with the XM brand H.265 NVR, If you use the Dahua or HIK camera H.265, will not support H.265, sometimes H.264 also can not work) |
|
Image Sensor |
XM510 For 720P 960P, HI3516E For 1080P |
|
DSP |
H62/H42(720P) H65(960P) 2235 (1080P) |
|
Horizontal Resolution |
1.0Megapixel/1.3Megapixel/2.0Megapixal |
|
Effective Pixels |
1280×720/1280×960/1920×1080(H/V) |
|
TV System |
Digital |
|
Sync System |
Internal |
|
Usable Illumination |
color 0.1LuxaF1.2,black/white 0.01LuxaF1.2 |
|
S/N Ratio |
≥55dB(AGC Off) |
|
Video Output |
1ch Digital high resolution output |
|
LENS |
|
|
Focal Length |
2.8,3.6mm (6mm optional) |
|
Lens Type |
Fixed |
|
OPERATIONAL |
|
|
DAY & NIGHT |
Auto |
|
ICR |
YES |
|
2DNR/3DNR |
YES |
|
Frame |
1280×720@25 fps 1920×1080@15fps |
|
Network interface |
1*RJ45 10/100M adaptive Ethernet port;support RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP etc |
|
Singal interface |
One photo resistance interface,one IR-CUT interface ,support photo resistance signal and IR-CUT links to IR |
|
White Balance |
Auto |
|
Gama Correction |
>R0.45 |
|
Electronic Shutter Speed |
4/25s~1/45,000s |
|
BLC |
Auto |
|
Gain Control |
Auto |
|
LED |
24 LEDs |
|
IR Status |
Under 15 Lux By CDS |
|
IR Power On |
CDS Auto Control |
|
IR Distance |
25M |
|
Power Consumption |
<3W |
|
Power Supply |
DC12V ±10% |
|
MECHANICAL |
|
|
Weatherproof Housing |
IP66 |
|
Color/Material |
White |
|
Cut-proof Bracket |
YES |
|
Operation Temperature |
under-10℃~ +50℃RH95% Max |
|
Storage Temperature |
under20℃~ +60℃RH95% Max |
|
Weight |
0.32KG |
|
Dimensions (W×H×D) |
180.7×62×62mm |
|
PACKAGE |
|
|
1 PCS |
Camera(Normally we will send with and without logo in random,if you need logo,please leave message into the order.)/ This camera include the waterproof parts. |
|
1 PCS |
CD / Waterproof parts |
Q:What’s the default ip address of the camera ?
F: 192.168.1.10 Username : admin Password : null ( empty ) !
Q: Does the camera supports Motion Detect,FTP,Email alarm, RTSP and so on ?
F: Yes ! All the IP Cameras we are selling supports these functions .
1) Please Setup the motion detection in the CMS software .
2) We suggest the Sever-U and FileZilla FTP Server to upload the video or image.
3) For the Email alarm,please use Email server which supports SMTP ( Hotmail ,Yahoo not support SMTP ,try Gmail please ) .
4) ,RTSP URL for VLC media Player :
rtsp://$(IP):$(PORT)/user=$(USER)&password=$(PWD)&channel=$(Channel)&stream=$(Stream).sdp?real_stream
Example : rtsp://10.6.10.25:554/user=admin&password=&channel=1&stream=0.sdp?real_stream
F: What’re the ports information of the cameras ?
Q : ONVIF 2.0 Port 8899 ;RTSP Port 554 ;HTTP Port 80;Media Port 34567
F:Does the camera support IE ,Chrome ,Firefox and so on ?
Q: Since the plug-in problem ,for website interface IP address URL,ONLY IE supports Multi Language . Chrome,Safari just support Chinese .
For cloud server XMEYE.NET ,it supports multi language
Q:When I finish the steps to add the camera to the CMS list,why it notify “ Can’t find the Device “ even I can see the default ip address 192.168.1.10 in the menu .
F: It is the IP Address conflict ,the default ip address is not in the same network segment as your router.
Please click “Edit Device “ to change the camera’s ip address to make them in the same network segment !
For example ,if your router’s ip address is 192.168.0.1 ,then you need to change the camera’s ip address to 192.168.0.XX .
Item Display on CMS Client
If you do not know how to use the CMS Client to contact the Camera,please leave the email in the order to ask seller send the manual to email.
Please make sure your router gateway is the same as this camera "1", after contact success,you can change to another gateway and ip address as you need.
Item Display on Local Internet
If you need contact by Local internet, we recommend you can contact the camera to the CMS Client first,
after contact CMS, Local control will be easy.
Item Display on www.xmeye.net
After you contact the local internet success, you can use other PC anywhere to control the camera,
Just use the camera Serial Number.
How to contact to the APP?
1: Download the APP from the APP store. Contact the camera to Router or the swich by RJ45 Cable.
2: You can use the local visit to search the camera address, it will show the camera serial number of the name.
